Power Supply

Connect Tech offers 12V 2A power supplies preconfigured for the ASG002. It is supplied by a standard AC
line cord and has a cable length of approximately 1.5m. Contact our sales department about the MSG063 or
MSG071 for more details. View the MSG063 drawing.

On-Board Indicator LED's

The Elroy Carrier has 4 on-board indicator LEDs.

Current Consumption Details

Below are the maximum ratings of the Elroy Carrier.
Theoretical Maximum
Theoretical absolute maximum total draw of all functionality on the
Elroy Carrier Board (not including TX2/TX2i/TX1 Module)
Below are measurements taken with the Elroy Carrier running in various configurations. Some values will
change depending on what operation or software is installed. Measurements also include the Jetson™
TX2/TX2i/TX1 Module. No mSATA or miniPCIe modules were installed while taking these measurements.
All measurements were taken in a lab environment with an ambient temperature of 25 degrees Celsius.
Actual Measurements
Module not installed, power applied to Elroy Carrier only
Module installed, booted into Ubuntu, idle
Module Installed, booted into Ubuntu, running a NVStreamer Demo
with a USB camera and 1080p video
Document: CTIM-00465
Revision: 0.16
LED Description
D7 GBE ACT#
D8 GBE LINK#
D15
D16 +3.3V_SB
Page 26 of 30
Connect Tech Inc. 800-426-8979 | 519-836-1291
®
Elroy Carrier for NVIDIA
+1.5V
Jetson™ TX2/TX2i/TX1
Users Guide
www.connecttech.com
Watts
7.5
Watts
0.75
6.12
12.3
Date: 2019-02-20
