INTRODUCTION

Connect Tech's FPD-Link III camera platform is an expansion board that allows up to 8 cameras to be
connected to the NVIDIA® Jetson AGX™ modules. We designed this platform for easy integration with
Connect Tech Carriers for the NVIDIA Jetson AGX Xavier™ and AGX Orin™ modules. Power to the
cameras is provided by PoC (Power over Coax) so all the data, control signals, and power are sent
through a single 50 Ohm Coaxial cable. This allows for flexibility in cable routing and ease of installation
in automotive applications.
The main power for the board comes from the Camera Expansion Header. The 12V power for the
cameras is also available from the same header on applicable Connect Tech Carriers for Jetson AGX
Xavier™ and AGX Orin™. A hot pluggable external +9 to +24V connector is available on the JCB006 for
applications where more power to the cameras is required (i.e 4 or more cameras). The circuit will
always take the external voltage if both are connected within the valid range of voltage.

Product Features and Specifications

PCB Size
Weight
NVIDIA® Xavier™
Connection (Uplink)
Camera Inputs (FPDLINK)
Deserializer
MIPI Output
Camera Input Connectors
PoC (Power-Over-COAX)
Power
Operating Temperature
Warranty and Support
Mechanical Dimensions
Document: CTIM-00061
Revision: 0.00
Specifications
75mm x 57mm
38g
1x High Density Connector
Camera Board will mate to the NVIDIA® Jetson™ "Camera Expansion
Header"
8x Total
TI DS90UB954-Q1
A single 4-lane MIPI CSI-2 v1.3 output from each (4) Deserializer
(16-lanes total)
2x MATE-AX Quad Coax Connectors
Breakout cables to FAKRA available
All 8 cameras will be sourced 12V Power-Over-COAX from JCB006
Directly powered from Camera Expansion Header or External +9 to 24V
Input
-40°C to +85°C
1 Year Warranty and Free Technical Support
57.00mm x 75mm
