• OFF
If you do not use "Speaker B" or "BI-AMP",
select "OFF".
Note
Set "SB Assign" to "OFF", then connect the
surround back speakers to this receiver when you
want to change the connection from a bi-amplifier
connection or speakers front B connection to a
surround back speakers connection. Re-set up the
speakers after you connect the surround back
speakers. See "Calibrating the appropriate speaker
settings automatically (Auto Calibration)"
(page 38).

Manual Setup

You can adjust each speaker manually on the
"Manual Setup" screen. You can also adjust
the speaker levels after the Auto Calibration is
completed.
To adjust the speaker level
You can adjust each speaker's level (front left/
right, front left/right high, center, surround
left/right, surround back left/right,
subwoofer).
1
Press V/v/B/b repeatedly to select the
speaker on the screen for which you
want to adjust the level, then press
2
Press B/b repeatedly to select "Lvl:".
3
Press V/v repeatedly to set the level of
the selected speaker, then press
For front left/right speakers, you can adjust
the level from –10.0 dB to +10.0 dB in
0.5 dB steps. For other speakers, you can
adjust the level from –20.0 dB to +10.0 dB
in 0.5 dB steps.
Note
When one of the sound fields for music is selected,
no sound is output from the subwoofer if all the
speakers are set to "Large". However, the sound will
be output from the subwoofer if
– the digital input signal contains LFE signals.
– the front or surround speakers are set to "Small".
– the sound field for movie is selected.
– "Portable Audio" is selected.
GB
92
To adjust the distance from the
seating position to each
speaker
You can adjust the distance from the listening
position to each speaker (front left/right, front
left/right high, center, surround left/right,
surround back left/right, subwoofer).
1
Press V/v/B/b repeatedly to select the
speaker on the screen for which you
want to adjust the distance from the
seating position, then press
2
Press B/b repeatedly to select "Dist:".
3
Press V/v repeatedly to set the
distance of the selected speaker, then
press
You can adjust the distance from 3 feet
3 inches to 32 feet 9 inches (1.00 meter to
10.00 meters) in 1 inch (0.01 meter) steps.
Notes
• Depending on the speaker pattern setting, some
parameters may not be available.
• This function does not work in the following cases.
– Sound Field is set to "Analog Direct".
– Signals with a sampling frequency of more than
96 kHz are being received.
To adjust the size of each
speaker
.
You can adjust each speaker's (front left/right,
front left/right high, center, surround left/right,
surround back left/right) size.
.
1
Press V/v/B/b repeatedly to select the
speaker on the screen for which you
want to adjust the size, then press
2
Press B/b repeatedly to select "Size:".
.
.
.
