SAFETY
FOR LIFE
Before Placing the Control and
the Recloser into Service
CAUTION: Equipment misoperation. Do not
connect this control to an energized recloser
until all control settings have been properly pro-
grammed and verified. Refer to the programming
information for this control. Failure to comply can
result in control and recloser misoperation, equip-
ment damage, and personal injury.
Prior to placing the control and recloser into service, the
following installation procedures must be properly com-
pleted and verified:
1. Control properly mounted for the installation.
2. Recloser installed according to all locally approved
standards and practices.
WARNING: Hazardous voltage. Recloser and
control must be solidly grounded. Follow all
locally approved procedures and safety practices when
grounding this equipment. Improper grounding can
result in contact with high voltage, which will cause
death or severe personal injury.
3. Control and recloser properly grounded in accordance
with guidelines in this manual.
4. Control cable properly connected and supported.
5. Control battery connected and tested for proper
operation.
6. AC power connected to the control. (AC power LED
indicator is ON.)
7. All control programming entered and verified by
appropriate personnel.
8. Control clock set to the correct time.
9. Customer connections for remote and supervisory
operation checked and completed in accordance with
proper shielding and surge protection.
CAUTION: Equipment misoperation. Do not
connect this control to an energized recloser
until all control settings have been properly pro-
grammed and verified. Refer to the programming
information for this control. Failure to comply can
result in control and recloser misoperation, equip-
ment damage, and personal injury.
G110.3
IMPORTANT: The Form 5/Triple-Single recloser con-
trol can be taken out of service for testing and placed
back into service without de-energizing its recloser and
interrupting the system. However, during the time the
control is out of service, the recloser is inoperative.

Testing an Installed Control

The following tests to determine initial operation of the
Form 5/Triple-Single control can be performed while con-
nected to an operating recloser. This is the only test per-
formed on an installed, operating control. The Electrical
Testing of NOVA-TS Triple-Single Reclosers test
described in this section requires the Form 5/Triple-Single
control to be removed from service, connected to a
G115.1
bypassed recloser or tested at a location where the proper
testing equipment is available.
1. Turn on the operator panel display by pressing the
CHANGE/LAMP TEST button on the control operator
panel.
2. Scroll through the LCD display messages as
described in the LCD Display Messages section of
these instructions. See Form 5/Triple-Single Control
Operator Panel section of this manual.
Check the operational values for currents, voltages,
and other metering information.
3. Check that the LED for AC power is illuminated on the
control operator panel. This indicates the presence of
AC power.
4. Test battery operation, using the procedures
described in the Battery Test Procedure section of
these instructions.
S280-42-3

TESTING

G110.3
