Cooper Kyle Form 5/Triple-Single Installation Instructions Manual page 40

Kyle Form 5/Triple-Single Microprocessor-Based Recloser Control Installation and Operation Instructions
240Vac CLOSING
OPTION
YØ VOLTAGE
CLOSING
VOLTAGE
BØ VOLTAGE
SOURCE 2
SOURCE 1
AC
CUSTOMER
SOURCE 2
CONNECTIONS
POWER
POWER
SOURCE
OUTPUT
*NEUTRAL
AC
CUSTOMER
SOURCE 1
CONNECTIONS
POWER
*REQUIRED FOR
CONTROL OPERATION
Figure 39.
Form 5/Triple-Single and Form 5/Triple-Single UDP Power and Low Voltage Closing customer connections to
terminal block TB1 (Single-Phase Connection, Standard BØ Input).
240Vac CLOSING
OPTION
Y' VOLTAGE
CLOSING
VOLTAGE B' VOLTAGE
SOURCE 2
SOURCE 1
AC
CUSTOMER
SOURCE 2
CONNECTIONS
POWER
POWER
SOURCE
OUTPUT
*NEUTRAL
AC
CUSTOMER
SOURCE 1
CONNECTIONS
POWER
*REQUIRED FOR
CONTROL OPERATION
Figure 40.
Form 5/Triple-Single and Form 5/Triple-Single UDP Power and Low Voltage Closing customer connections to
terminal block TB1 (Single-Phase Connection, AØ Input).
40
