Form 5/Triple-Single and Form 5/Triple-Single UDP Control DIF Module 1
The 12 outputs of the DIF Module are Form C relay contacts. Six of the outputs are latching and six are non-latching.
Note: Contacts shown in inactive mode.
Output Connector
1 P3-1 (NC) Ground Trip Blocked
P3-2 (NO)
2 P3-3 (NC) Non-Reclosing
P3-4 (NO)
3 P3-5 (NC) Battery Test
P3-6 (NO)
4 P3-7 (NC) Hot Line Tag
P3-8 (NO)
5 P3-9 (NC) Normal Profile
P3-10 (NO)
6 P3-11 (NC) Supervisory Blocked
P3-12 (NO)
7 P2-1 (NO) Phase A Lockout
P2-2 (NC)
8 P2-3 (NO) Phase B Lockout
P2-4 (NC)
9 P2-5 (NO) Phase C Lockout
P2-6 (NC)
10 P2-7 (NO) Phase A Closed
P2-8 (NC)
11 P2-9 (NO) Phase B Closed
P2-10 (NC)
12 P2-11 (NO) Phase C Closed
P2-12 (NC)
Outputs
Function Type
unlatched
unlatched
unlatched
unlatched
unlatched
unlatched
Latched
Latched
Latched
Latched
Latched
Latched
Description
Ground Trip Blocked causes the control to block ground trip-
ping operations. This output is active when the GND TRIP
BLOCKED INDICATOR on the operator panel is illuminated.
This output is active when the NON-RECLOSING indicator
in the operator panel is illuminated.
This output is active when the BATTERY TEST indicator on
the operator panel is illuminated. This is a momentary
function.
With Hot Line Tag active, close circuit is disabled and the
HOT LINE TAG indicator is illuminated. With Hot Line Tag
inactive, the control switched back to the previous time cur-
rent curve for the active profile, close circuit is enabled and
the HOT LINE TAG indicator is off. This output is active
when the operator panel indicator is illuminated.
Normal Profile is active only when Alternate Profiles are
inactive. Normal reclosing operations will follow.
Supervisory Blocked prevents operation from supervisory
control. Programming is accessible from the operator panel.
This output is active when the SUPERVISORY BLOCKED
indicator on the operator panel is illuminated.
These outputs are active when the respective phase has
locked out.
These outputs are active when the respective phase has
closed.
