Kyle Form 5/Triple-Single Microprocessor-Based Recloser Control Installation and Operation Instructions
LCD Display Screens
Every screen contains a parameter name, parameter
value, and parameter units. If the control detects that a
parameter value is invalid, the LCD display shows five
dash characters (- - - - -) in the value field of the message.
Demand metered values are indicated by (D) and instan-
taneous values by (I).
Screen 1 - Instantaneous Load Current
Screen 1 displays line current values present for the last
overcurrent trip operation. Values are reset to zero when
the fault targets are reset.
1 Gnd ____________ A
Ph1-2 ____________ A
Ph3-4 ____________ A
Ph5-6 ____________ A
Screen 2 - Fault Targets
2 Gnd Fault ____________ A
Ph1-2 Fault ____________ A
Ph3-4 Fault ____________ A
Ph5-6 Fault ____________ A
Screen 3 - Frequency Trip
3 Freq Trip____________ Hz
Time Date
Present Freq ____________ Hz
Screen 4 - Voltage Trip
4 Ph1-N VTrip ____________ V
Ph3-N VTrip ____________ V
Ph5-N VTrip ____________ V
Time Date
Screen 5 - Power kWh
5 Tot ____________ kWh
Ph1-2 ____________ kWh
Ph3-4 ____________ kWh
Ph5-6 ____________ kWh
10
Screen 6 - S1 Phase-to-Neutral, Instant. Voltage
6 Instant S1 Ph-N
Ph1-N ____________ V
Ph3-N ____________ V
Ph5-N ____________ V
Screen 7 - S1 Phase-to-Phase, Instant. Voltage
7 Instant S1 Ph-Ph
Ph1-3 ____________ V
Ph3-5 ____________ V
Ph5-1 ____________ V
Screen 8 - S2 Phase-to-Neutral, Instant. Voltage
8 Instant S2 Ph-N
Ph2-N ____________ V
Ph4-N ____________ V
Ph6-N ____________ V
Screen 9 - S2 Phase-to-Phase, Instant. Voltage
9 Instant S2 Ph-Ph
Ph2-4 ____________ V
Ph4-6 ____________ V
Ph6-2 ____________ V
Screen 10 - Instantaneous Voltage
10 Instant S1-S2
Ph1-2 Dif ____________ V
Ph3-4 Dif ____________ V
Ph5-6 Dif ____________ V
Screen 11 - Real Power
11 Tot ____________ kW
Ph1-2 ____________ kW
Ph3-4 ____________ kW
Ph5-6 ____________ kW
