Kyle Form 5/Triple-Single Microprocessor-Based Recloser Control Installation and Operation Instructions
Form 5/Triple-Single and Form 5/Triple-Single UDP Control DIF Module 2
The DIF inputs are factory-configured as momentary or maintained functions. When Supervisory is blocked, Supervi-
sory signals are disabled, but Remote inputs are active. Whetting voltage for the DIF inputs is supplied by the DIF mod-
ule or by the user. The input voltage range is 12 to 120 VAC or VDC.
Input Connector
1 P4-1 Remote All Phases Trip & Reclose Remote Trip and Reclose initiates a trip operation followed by a
2 P4-2 Remote All Phases Lockout
3 P4-3 Remote All Phases Close
4 P4-4 Supervisory Normal Profile
5 P4-5 Supervisory Alternate Profile 1
6 P4-6 Supervisory Alternate Profile 2
7 P4-7 Supervisory Alternate Profile 3*
8 P4-8 Suprv. Cold-Load Pickup Blocked
9 P4-9 Supervisory Fast Trips Disabled
10 P4-10 Supervisory SGF Blocked
11 P4-11 Supervisory Battery Test
12 P4-12 Remote Hot Line Tag
**Note: Supervisory Alternate Profile 3 replaced by Switch
Mode on Form 5/Triple-Single UDP controls.
28
Inputs
Function
reclose operation on all three phases. A momentary signal is
required for proper operation.
This input is active with a whetting voltage and causes the control
to perform a trip operation followed by a reclose operation. This
input is active regardless of the state of the Supervisory function.
All phases trip open and the control locks out. The feature can be
used for tripping from external relays and alarms. A momentary sig-
nal is required for proper operation.
All phases close upon a remote signal from the control to the
reclosers.
Supervisory Normal Profile requires a momentary signal for proper
operation.
This input is active with a whetting voltage and causes the control
to select Normal Protection Profile. This input is inactive if the
Supervisory function is disabled.
Supervisory Alternate Profiles provides selection of alternate pro-
grammed values for phase and ground. This feature is activated by
a remote momentary signal.
These inputs are active with a momentary whetting voltage and
cause the control to select the respective Supervisory Alternate Pro-
file. The inputs are inactive if the Supervisory function is disabled.
This input performs the same function as the COLD LOAD PICKUP
BLOCKED key on the operator panel. This input is inactive if the
Supervisory function is disabled. A momentary signal is required
for proper operation.
This input performs the same function as the FAST TRIPS DISABLED
key on the operator panel and is inactive if the Supervisory function is
disabled. This is a momentary function.
This input is active with a momentary whetting voltage and
causes the control to block, or unblock sensitive ground fault oper-
ations. The input is inactive if the Supervisory function is disabled.
This input performs the same function as the BATTERY TEST key
on the operator panel. This input is inactive if the Supervisory func-
tion is disabled. This is a momentary function.
Remote Hot Line Tag performs the same function as the HOT LINE
TAG switch on the operator panel. Remote Hot line Tag is activated
by a maintained SCADA command, a serial command, or locally
via a operator panel switch. This input is active regardless of the
state of the supervisory function.
Description
