Form 5/Triple-Single and Form 5/Triple-Single UDP Control DIF Module 2
The 12 outputs of the DIF Module are Form C relay contacts. Six of the outputs are latching and six are non-latching.
Note: Contacts shown in inactive mode.
Output Connector
1 P3-1 (NC) Phase A Open
P3-2 (NO)
2 P3-3 (NC) Phase B Open
P3-4 (NO)
3 P3-5 (NC) Phase C Open
P3-6 (NO)
4 P3-7 (NC) Normal Profile
P3-8 (NO)
5 P3-9 (NC) Alternate Profile 1
P3-10 (NO)
6 P3-11 (NC) Alternate Profile 2
P3-12 (NO)
7 P2-1 (NO) Alternate Profile 3*
P2-2 (NC)
8 P2-3 (NO) Cold-Load Pickup Blocked
P2-4 (NC)
9 P2-5 (NO) Fast Trips Disabled
P2-6 (NC)
10 P2-7 (NO) Sensitive Ground Fault Blocked
P2-8 (NC)
11 P2-9 (NO) Battery Test
P2-10 (NC)
12 P2-11 (NO) Hot Line Tag
P2-12 (NC)
Note: Supervisory Alternate Profile 3 replaced by Switch
Mode on Form 5/Triple-Single UDP controls.
Outputs
Function Type
unlatched
unlatched
unlatched
unlatched
unlatched
unlatched
Latched
Latched
Latched
Latched
Latched
Latched
Description
The respective phase OPEN indicator is active when
the recloser signals the control that the respective
phase contacts are open.This output is active when the
respective PHASE OPEN indicator is illuminated.
Normal Profile is active when Alternate Profiles are
inactive. Normal reclosing will follow.
These outputs are active when the respective ALTER-
NATE PROFILE indicators are illuminated on the
operator panel.
This output is active when the COLD LOAD PICKUP
BLOCKED indicator on the operator panel is illuminated.
This output is active when the FAST TRIP DISABLED
indicator is illuminated.
Output is active when Sensitive Ground Fault is
blocked.
This output is active when the BATTERY TEST indica-
tor on the operator panel is illuminated. This is a
momentary function.
With Hot Line Tag active, close circuit is disabled and
the HOT LINE TAG indicator is illuminated. With Hot
Line Tag inactive, the control switched back to the pre-
vious time current curve for the active profile, close cir-
cuit is enabled and the HOT LINE TAG indicator is off.
This output is active when the operator panel indicator
is illuminated.
