3Com SuperStack II PathBuilder S330 Reference Manual page 184

172 C 5: P B
HAPTER ATH UILDER
S330 D P
IAGNOSTICS AND ERFORMANCE
Table 28 DS1/E1 UNI Module Alarms (continued)
Alarm Meaning
BAD SCCI Status and Change Control
(3Com Patent Indication – the content of the
Pending) ICP cells has changed. The far
end ICP cell SCCI in this link
does not agree with the SCCI
of the other links in the group.
Bad Symmetry The far end group symmetry
has changed in an IMA link.
Duplicated IMA ID An IMA group has received an
IMA ID that has been received
by a previous group. The
second group must have a
unique IMA ID.
Duplicated Link ID Duplicated far end logical link
ID in this IMA group for this
IMA link.
Each IMA group assigns a
unique Transmit link ID to each
link in the group. This link ID
should match the Receive link
ID of the remote end IMA
device. This alarm means that a
link received a Transmit link ID
already assigned to a previous
link.
Duplicated Offset Duplicated far end ICP cell
offset in this IMA group in an
IMA link.
Each IMA group assigns a
unique Transmit offset to each
link in the group. This alarm
means that a link received a
Transmit offset already
assigned to a previous link.
Some of the links are probably
misconnected.
Excessive Link Delay The link has exceeded the
user-selectable value for
acceptable link delay.
The link is removed from the
group.
Group [n] Abort Generated when Group [n]
Symmetry Config. Abort is generated,
due to group symmetry
problem
Group [n] Config The near end node rejects the
Abort far end IMA parameters.
ATM Forum (R-128)
Group [n] Degraded The IMA group is passing data
Service with less than the number of
IMA links you configured.
(continued)
S
TATISTICS
Troubleshooting Steps
Check the links for proper connection.
Reconnect if necessary.
Remove the link and stop Tx and Rx
data.
Check for loops and check the IMA
group configuration.
Check the links for proper connection.
Reconnect if necessary.
Check the links for proper connection.
Reconnect if necessary.
Check the links for proper connection.
Reconnect if necessary. Also try
adjusting the link delay parameter for
the IMA group.
Check and correct near end symmetry.
Only symmetric operation is supported
in PathBuilder products.
Check and correct the near end and far
end parameters for compatibility.
Continue passing data. Correct faulty
links or adjust IMA group
configuration.
