Operation and Setting

6.
6.1
6.1.1
Fig. 12 View on operating and display elements models CLS-K-10 up to -51
S2 Switch for light/dark changeover
Fig. 13 Operating and display elements models CLS-K-10 up to -51
1) Not available with all versions
optoCONTROL CLS-K
Operation and Setting

Operation and Display Elements

Models CLS-K-10 up to -51

LED green LED red
S1 Range switching
P2 Potentiometer for timer
1
P1 Potentiometer sensitivity
1
