Operation and Setting
6.2.5
6.2.5.1
You will find the description in detail, see Chap. 6.2.2.1, see Chap. 6.2.2.2.
1
2
3
Fig. 22 Operating and display elements model CLS-K-63 / special functions
optoCONTROL CLS-K

Special Function for CLS-K-63

Setting Reflex Operation / Transmitted Light Mode

Turn potentiometer P1 (sensitivity) clockwise until the LED changes from green to red (Max.
15 turns).
In the case of a large scanning range S1 set to
Adjust the range analogously in the case of adjusted and free light path, see Chap. 6.2.2.1.
P3 OFFSET
zero offset
LED green LED red
S1 Range switching
Far.
P2 Additional amplification
(signal spreading)
Measuring point GND
Measuring point U
S2
1 2
Selecting switch analog output
1 = Basic function
2 = Output
P1 Potentiometer sensitivity
0 - 10 mA (63)
0 - 20 mA (63)
Page 31
