Operation and Setting
P1 potentiometer
Fig. 18 Settings of the potentiometer P1 and range switch S1
6.2
The warm-up time of the amplifier is approximately 10 min.
6.2.1
1) P1 = Potentiometer sensitivity
optoCONTROL CLS-K
S1 range switch
1
Far

Commissioning

After the assembly, set the range switch S1 on

Range Switching S1

Near In the case of overregulation of the amplifier (analog signal > 5 V), the sensitivity can be
reduced by the Near setting.
Far In the case of a too small scanning range /range an increase can be achieved by the Far
setting.
Shift the range switch S1 into the reverse position, if no Near or Far setting can be effected with the
sensitivity potentiometer.
Please use a different fiber optics or change the position of the fiber optics, if even with this measure
setting is not possible.
LED
Near
Near, see Fig. 18.
Page 26
