Operation and Setting
6.1.2
Fig. 14 View on operating and display elements model CLS-K-61
LED green
LED red
S1 Range switching
Fig. 15 Operating and display elements model CLS-K-61
optoCONTROL CLS-K

Model CLS-K-61

P3 OFFSET
P2 Additional amplification
zero offset
(Signal spreading)
Display
P1 Potentiometer sensitivity
S2
1 2
Selector switch analog output
1 Basic function 0.1 - 5 VDC
2 Output 0 - 10 VDC
Page 24
