Mounting
4.1
Various fiber optics are available for the optoCONTROL CLS-K, siehe Kap.
probe even in confined conditions.
The fiber optics is inserted into the provided adapter and locked with the cap nut, see Chap. 4.2.
i
Treat the fiber optics carefully. Do not fall below the bending radius of the fiber optics (3 x the outside diame-
NOTICE
ter).
> Breakage of the fiber optics fibers
> Impairment of the switching behaviors
Do not touch the front surface of the probe.
> Impairment of functionality by contamination
Do not install more fiber optics probes directly next to each other.
> Mutual interference
Do not use cable ties in order to fasten the PVC coating.
> Breakage of the fiber optics fibers
optoCONTROL CLS-K

Fiber Optics

The male connector of fiber optics is coded on the amplifier side and must not be plugged in by force!
A 1. It is possible to use an optimal
