Introduction

On a Variable Speed Drive such as Unidrive, timing functions necessary for
the correct operation of power devices are performed by its own
microprocessor operating in real-time. This imposes limitations on the
microprocessor when carrying out other duties, resulting in a reduction of
flexibility of the Drive.
To maximize this flexibility, a second processor can be used for running
application-specific software. This second microprocessor is the
which allows the Drive to be easily adapted to applications by programming
software in the
1.1

Overview

The is a compact microcomputer contained in a Large Option Module
UD70
for easy installation in any size of Unidrive.
Together with the
software or use pre-written software in order to enhance the flexibility of a
Unidrive.
DPL Toolkit (Windows™ interface)
The DPL Toolkit is contained on two diskettes. It is a program which runs in
Microsoft® Windows™ Version 3.1x and Windows™ 95. Programs for the
are written on a host
UD70
The uses a high-level programming language called DPL
UD70
(Drive Programming Language) which is in many respects similar to the
BASIC language. DPL is a compiled program which gives it the ability to run
at high speed.
The DPL Toolkit is used to write, compile and download a DPL program to an
. The Toolkit also has a comprehensive set of de-bugging facilities to
UD70
aid the development and testing of the DPL program.
Connection between the
communications link. This link need only be used during program
development, testing and commissioning. It can be disconnected after the
software has been successfully loaded.
UD70
Issue code: 70nu2
.
UD70
Toolkit, the allows the programmer to write
DPL UD70
using the DPL Toolkit.
PC
and host PC is via an
UD70
UD70
DPL
serial
RS232
Introduction 1-1
