Menu 88
Status parameters
Parameter
#88.01
Menu 80
I/O Box parameters
Parameter Menu 80
number analog IN
0 Null
1 ADC1 (±4000)
2 ADC2 (±1000)
3 ADC3 (±1000)
4 ADC4 (±1000)
5 ADC5 (±1000)
....
32
40
41
42
43
44
45
46
Note
Menus 81 and 83 parameters are write only parameters.
They cannot be read back via the serial comms link.
10-10 Parameters
Function
READ Run-time error code. Only valid in ERROR task.
WRITE Writing a value of 1070 resets the UD70.
See Advanced error-handling in Chapter 9 Diagnostics.
Menu 81 Menu 82
analog OUT digital IN
Null Null
DAC1 (±1000) bit 1
DAC2 (±1000) bit 2
DAC3 (±1000) bit 3
bit 4
bit 5
bit 32
bits 1 – 8
bits 9 – 16
bits 17 – 24
bits 25 – 32
bits 1 – 16
bits 17 – 32
bits 9 – 32
Menu 83 Menu 84
digital OUT control
Null Null
bit 1 0 = ADC1
1 = 4–20mA
bit 2
bit 3
bit 4
bit 5
bit 32
bits 1 – 8
bits 9 – 16
bits 17 – 24
bits 25 – 32
bits 1 – 16
bits 17 – 32
bits 9 – 32
