Introduction

NOTE
Unidrive parameters are denoted in this manual by "#MM.PP", where
MM refers to the menu number, and PP refers to the parameter
number within that menu. Please refer to the Unidrive Advanced User
Guide for a full list of parameter definitions.
1.1

DeviceNet Interface for Unidrive

The Unidrive DeviceNet interface is supplied as an option module, with
the DeviceNet using a UD70 as the host. The UD70 does not lose any
functionality when the DeviceNet interface is fitted. The fastest data
rate currently supported is 500 Kbits/sec.
The Unidrive supplies all power requirements for the Unidrive
DeviceNet interface. A DeviceNet network power supply must also be
connected, but this power supply does NOT keep the UD70 powered up
when the Unidrive is switched off.
1.2

Product Conformance Certification

The Unidrive DeviceNet interface was submitted to the Open DeviceNet
Vendors Association for conformance testing. All tests were successful,
and the Unidrive DeviceNet interface was awarded full DeviceNet
Conformance Certification.
"www.odva.org"for further details.
1.3

Overview Specification

•
Supported data rates (bits/sec): 500k, 250k, 125k
•
Three polled 16 bit input/output words, all can be mapped to and
from Unidrive parameters
•
Explicit data allows access to all Unidrive parameters
•
6 DeviceNet Drive Profiles supported
Issue Number: 2
Refer to the ODVA Web Site at
