Introduction

1.1

Main features of the UD55

Note
The UD55 can be used only with Drives equipped with
version 3 (or later) software. (Parameter 0.50 indicates
the software version.)
All references to the Advanced Menus in this User Guide
are not applicable when using the UD55 with the
Commander GP Drive.
The UD55 Cloning small option module can store up to eight parameter-sets
Parameter-
which contain all the read–write parameters for a Drive, and include those
sets
in Menus 16 and 20, when applicable. These parameter-sets can be
individually recalled for loading into the same or another Drive.
Operating Cloning of Drives can be performed only when the operating mode
(Open-loop, Closed-loop Vector, Servo or Regen) of the destination Drive
modes
is the same as that of the source Drive.
Installation The UD55 must be fitted in the small option module bay of the Unidrive. All
connections to the Drive are made by a multi-way connector. Connections
from external equipment are made to a plug-in 16-way screw-terminal block
on the UD55.
