CHAPTER 7– SERVICE AND REPAIR

Overview Parts List and Part Numbers

The Toptech replacement part numbers are shown in the table below:
Part
EXL Display Assembly
EXL Prox Card Reader
EXL Keypad
EXL Keypad Barrier (1.1)
EXL Keypad Barrier (2.0)
Magnetic Switch Assembly
Magnetic Bolt Assembly
Display Interface Cable
EXL backlight power cable
78
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
Part Number Part
1667 AC Power Supply Board :
1669 Revision 1.0, 1.1
1638 Revision 1.2
obsolete DC Power Supply Board :
2710 Revision 1.0, 1.1
Revision 1.2
1900 I/O Board :
1901 Digital/ Analog I/O, revision 1.3
1250 2 Meter I/O Board, revision 1.2
1663 CPU Board :
Revision 1.0, 2.0
Revision 2.1
Part Number
obsolete
4728
obsolete
4729
4718
4723
obsolete
4727
