CHAPTER 6– CONFIGURATIONS

Field Modification and Data Entry

MultiLoad II/ RCU II will have all fields populated with default values. There are two types of fields,
toggle or data entry. Toggle fields contain a number of choices. Scroll through the choices by pressing
the Enter key. Data entry fields require that a value be entered into the field within a given, applicable
range. In the example below, RCU Address field is highlighted:
Press Enter to choose the field. A blinking cursor indicates that data can be entered.
Type in the new value (e.g. 123) and press Enter. The new value displays on the screen.
61
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
RCU GENERAL SETUP
RCU Address:
Card Reader:
Processing Mode :
Swing Arn Secondary:
Terminal Name: Toptech Terminal
Security Accounts
Next Prev
RCU GENERAL SETUP
RCU Address:
Card Reader:
Processing Mode:
Swing Arm Secondary:
Terminal Name: Toptech Terminal
Security Accounts
Enter
001
DISABLD
Remote
DISABLD
Exit Enter
█
DISABLD
Remote
DISABLD
Exit
