CHAPTER 7– SERVICE AND REPAIR

Chapter 7 Service and Repair

Do not service MultiLoad II/ RCU II without disconnecting the supply circuit. Keep
the enclosure tightly closed while circuits are live.
Using a magnetic screwdriver is very helpful in retaining the screws during removal and
installation.

Overview and Subassemblies

Figure 7.1 MultiLoad II (ML II) / Remote Control Unit II (RCU II) Explosion Proof Lite Unit
67
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
DISPLAY
KEYPAD
CARD READER SLOT
DISPLAY
