CHAPTER 6– CONFIGURATIONS

Chapter 6 Configurations

Switch Access Control

The MultiLoad II contains switches which limit menu and configuration access. These switches limit
users from accessing Program Mode, as well as from changing Weights and Measures controlled
parameters.
In Program Mode, the operator has access to the following:
- The Configuration Menu parameters.
- The Diagnostics Menu and its functions.
- Other administrative procedures, such as clearing high-level alarms.
To access Program Mode, the MultiLoad II/ RCU II terminal operator must:
Move the Program Mode switch into the active position.
1.
At the idle card-in screen, enter the security code (default security code is 000000) and press
2.
the Next key.

External Switch Access Control (MultiLoad II Only)

One access control switch option is a pair of external access control switches. These switches limit
access to Program Mode and changes to Weights and Measures controlled parameters.
E
XTERNAL SWITCHES SERVE NO FUNCTION ON THE
OVERRIDES THE PROGRAM SWITCH SETTING
UNDEFINED FOR THE
Y W
OUR LOCAL
SEAL AND CHANGING PARAMETERS
TEMPERATURE CALIBRATION
56
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
RCU II.
M
EIGHTS AND EASURES OFFICE MAY NEED TO BE CONTACTED AFTER BREAKING THE
. T
HIS IS TYPICALLY DONE ONLY DURING METER PROVING OR
.
RCU II
SINCE PASSWORD ACCESS ALWAYS
. W
EIGHTS AND MEASURES FUNCTIONALITY IS
6
Chapter
