CHAPTER 5– CONNECTING FIELD DEVICES TO THE I/O BOARD

How to Connect and Wire Field Devices to the I/O Boards

In this section of the chapter we will provide examples of commonly used devices that can get wired to
the I/O boards. This is not an exhaustive listing, but intended to provide you an example of how certain
types of I/O need to get wired into the various boards.
MultiLoad II Wiring Examples:
- Flow Meter and Control Valve
- Additive
-
RTD
-
Analog In & Analog Out
-
AC Output Wiring
-
AC Input Wiring
-
DC Input Wiring: Permissives/Status
- DC Output Wiring
- 2 Output Air Eliminator Wiring
-
Remote Display Wiring
RCUII Wiring Examples:
- DC Input Wiring
-
AC: DC Output wiring
Typical Example:
-
Typical single meter example
