CHAPTER 5– CONNECTING FIELD DEVICES TO THE I/O BOARD

2 Meter I/O Board (IO-2M)

TB4
1
100Ω
Pt
°C
°F
4
TB5
1
100Ω
Pt
°C
°F
4
TB6
1
+
12V
5V
-
4
TB7
1
+
-
90°
+
-
+
6
-
TB8
1
+
-
90°
+
-
+
6
-
TB9
1
+
-
+
-
4
Figure 5.2
38
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
IO_2M
METER 0, RTD
METER 1, RTD
12 Vdc
0°
METER 0, PORT 4
A
METER 0, PORT 5/6
B
METER 0, PORT 7
0°
METER 1, PORT 4
A
METER 1, PORT 5/6
B
METER 1, PORT 7
METER 0, PORT 10
METER 1, PORT 10
2 Meter I/O Board Terminal Block Assignments
METER 0, PORT 0
METER 0, PORT 1
METER 0, PORT 2
METER 0, PORT 3
LINE
METER 1, PORT 0
METER 1, PORT 1
METER 1, PORT 2
METER 1, PORT 3
LINE
METER 0, PORT 8
METER 1, PORT 8
TB3
5
1
TB2
5
1
TB1
4
L
N
L
1
N
