Toptech MultiLoad II EXL Installation Manual page 64

CHAPTER 6– CONFIGURATIONS
MultiLoad II (2 pages)
C O N F I G U R A T I O N
Communication
Network
RCU General Setup
RCU Setup
Security Setup
Equipment Setup
FCm Type Setup
Alarm Setup
Products
Additive Cal.
Remote Adtv Cal.
Access ID's
Custom Logic
Customer Logo Setup
Next Prev
C O N F I G U R A T I O N
Date & Time
Printing
Trace
Reports
Next Prev
Press Enter and key in RCU Address (001, or as desired) for the MultiLoad II/ RCU II:
7)
MultiLoad II
RCU GENERAL SETUP
RCU Address:
Card Reader:
Processing Mode:
Swing Arm Secondary:
Terminal Name: Toptech Terminal
Security Accounts
Next Prev
Press Enter to save, then press Exit to return to the Configuration Menu.
8)
Press Exit to return to the Main Menu.
9)
When finished with configuration or diagnostics, please reset MultiLoad external switches (see 6.1).
10)
64
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
M E N U
Exit ENTER
M E N U
Exit Enter
001
DISABLD
Remote
DISABLD
Exit Enter
RCU II
C O N F I G U R A T I O N
Communication
Network
RCU Setup
Customer Logo Setup
Date & Time
Next Prev
RCU II
RCU GENERAL SETUP
RCU Address:
Card Reader: DISABLD
Password:
Security:
RCUOP Protocol:
Next Prev
M E N U
Exit Enter
001
*****
DISABLD
DISABLD
Exit Enter
