CHAPTER 6– CONFIGURATIONS

Verifying Communications between MultiLoad II/ RCU II and I/O Board

Enter program mode by pressing 00000 on the keypad, then press Next key.
1)
Select diagnostics from main menu:
2)
MultiLoad II
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
PTB Serial –Test
Network Test
Keypad
Display
Unicode
FCM Com
PCM Com
FCM Health
PCM Health
RCU
Bay
Next Prev
For MultiLoad II, select FCM COM. For RCU II, select RCU:
3)
MultiLoad II
000 FCM COM DIAGNOSTICS
00-Ok
If screen displays "00-OK" (or "I/O Board Com: OK" for the RCU II), the I/O board is communicating
4)
with the MultiLoad II or RCU II.
If the I/O board is not communicating the message "00-ERR" appears (or "I/O Board Com: ERR" for
5)
the RCU II).
If 00-ERR (or "I/O Board Com: ERR") appears, verify the communication parameters for Com0
6)
within the Communication Setup Menu. This menu is located under the Configuration Menu. The
Com0 communication settings required for the I/O board are .57.6 (K Baud), None (Parity), 8 Data
(bits), 1 Stop (bit), Single, and I/O Board (type of serial device). This is correctly set in the factory
when an RCU II is assembled, but it is possible for the settings to be updated by the installer.
65
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
M E N U
Preset
Meters
Components
Additives
Sampler
Custom Logic
Modbus Device
Thread Info
SD Card
Exit Enter
Exit
RCU II
D I A G N O S T I C S
Card Reader
COM Loopback
Serial Ports
Network Test
Keypad
Display
Unicode
RCU
Next Prev
RCU II
RCU I/O DIAGNOSTICS
I/O Board Com: Ok
Timeouts: 000000003
[1]AC Output 0 - OFF
[2]AC Output 1 - OFF
[3]AC Output 2 - OFF
[4]AC Output 3 - OFF
[5]AC Output 8 - OFF
[6]DC Output 10 – OFF
[7]DC Output 11 – OFF
[8]DC Output 12 – OFF
Exit
M E N U
Exit Enter
F/W Rev: 033
Com Lost: 000000001
DC Input 4 – OFF
DC Input 5 – OFF
DC Input 6 – OFF
DC Input 7 – OFF
DC Input 9 – OFF
Counter 4 - 00000
Counter 5 - 00000
Program Key– OFF
W&M Key – OFF
Battery @ 36C 3.24V
Battery 100%
Clear
