CHAPTER 5– CONNECTING FIELD DEVICES TO THE I/O BOARD
MultiLoad II Analog Wiring
5.4.4.1 RTD Wiring
I/O DIGITAL/
I/O 2 METER
ANALOG
METER 0
IO_DA TB4
IO_2M TB4
✓
V+
1
V+
✓
R+
2
R+
RTD
RTD
✓
R-
3
R-
✓
COM 4
COM 4
Note: All 4 wires MUST be run to the sensor. Do not simply jumper REF- to COM or REF+ to V+ at the FCM II. For 3-wire and 2 wire probes, the
connection of REF- to COM and REF+ to V+ should be as close as possible to the probe (within inches).
43
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
METER 1
RTD
IO_2M TB5
✓
✓
1
V+
1
°C
✓
✓
°F
2
R+
2
RTD
✓
✓
3
R-
3
RTD
✓
✓
COM 4
°C
°F
RTD
°C
°F
RTD.V+
100Ω
RTD.R+
Pt
RTD.R-
RTD.COM
RTD.V+
100Ω
RTD.R+
Pt
RTD.R-
RTD.COM
RTD.V+
RTD.R+
100Ω
RTD.R-
Pt
RTD.COM
100 Ω
α=0.00385
100 Ω
α=0.00385
100 Ω
α=0.00385
