CHAPTER 5– CONNECTING FIELD DEVICES TO THE I/O BOARD

RCU II DC Output Wiring

I/O DIGITAL/ I/O 2 METER
ANALOG METER 0
IO_DA TB3 IO_2M TB9
✓
IN 1 IN 1
PORT
PORT 10
✓ 0.10
OUT 2 OUT 2
✓
IN 3 IN 3
PORT 11
✓
OUT 4
OUT 4
✓
IN 5
PORT 12
✓
OUT 6
Note: This shows a typical configuration. DC outputs can be assigned to any unused DC output.
54
MultiLoad II/ RCU II Explosion Proof Lite (EXL) Installation Guide - Part # 6070
METER 1
IO_2M TB9
✓
IN 1
PORT 10/
✓
OUT 2 PORT 0.10
✓
PORT IN 3
✓
1.10
OUT 4
PORT 10/
PORT 1.10
5 – 30 Vdc
+
-
PORT 10.IN/ PORT 0.10.IN
+
PORT 10.OUT/ PORT 0.10.OUT
-
PORT 10.IN/ PORT 1.10.IN
+
PORT 10.OUT/ PORT 1.10.OUT
-
N
N.O.
+
L
C
N.C.
-
+
L N
-
