modbar av Series Manual page 9

This operating manual refers exclusively to the following models, of our own manufacture:
2
1
Espresso Taps
9
10
Barista Side
MODBAR AV 2 groups, Espresso System
Espresso Module
6
5
3
7
4
Fig. 1b - ESPRESSO System 2 groups
Legend
1 Espresso Tap 1
2 Espresso Tap 2
3 Tap 1 Brewing
4 Tap 2 Brewing
5 Tap 1 Low Voltage
6 Tap 2 Low Voltage
8
7 Tap 1 High Voltage
8 Tap 2 High Voltage
9 Tap 2 Coffee Boiler
10 Tap 1 Coffee Boiler
For additional information on electronics,
keypads, and software
please see the section entitled Software
Programming your Espresso Machine.
programming,
9
