This operating manual refers exclusively to the following models, of our own manufacture:
1
Espresso Tap
5
6
8
MODBAR AV 1 group, Espresso System
Espresso Module
2
4
Barista Side
Fig. 1a - ESPRESSO System 1 group
Legend
1 Espresso Tap 1
2 Tap 1 Brewing
3 Tap 1 Low Voltage
3
4 Tap 1 High Voltage
5 Preheater
6 Tap 1 Coffee Boiler
For additional information on electronics,
keypads, and
please see the section entitled Software
Programming your Espresso Machine.
software programming,
