modbar av Series Manual page 12

350 mm - 14 in.
Minimum clearance between
Espresso Taps
150 mm - 6 in.
Clearance above
75 mm - 3 in.
Clearance left side
200 mm - 8 in.
Clearance right side
Fig. 2 - Installation guide
12
Recommended Clearances
75 mm - 3 in.
Clearance rear
WARNING
Installation on the counter:
For cutting the counter refer to
cutting template placed inside
the package.
WARNING
Installation on the counter with
scales:
The thickness of the counter must
be between 20mm and 100mm.
WARNING
Replace fuses with the same size,
type and rating F1 = 2A, 250V
WARNING
This machine should not be
installed in kitchens.
