modbar av Series Manual page 84

"Technical" Programming
Scale Configuration
Enter Password
Scale
Configuration
Display
5 This parameter indicates that the scale is properly connected; navigate using the T1
G1 Scale
PRESENT
display the next menu.
6
Calibrate
Press the T3 button
G1 Scale
Remove any object from the scale, then press the T3 button
Empty G1 Scale
And Press Enter
Place the reference weights onto the scale, then press the T3 button
7
Place 100g on G1
the self-calibration values or a confirmation message are displayed.
And Press Enter
Repeat this operation for each group.
8
G1 Scale: v2.5.2
Press T2
Upgrade to 2.5.2
84
(only on ABR espresso machine models)
Description
• This parameter allows the operator to
view and manually change each dose for
each Selection Indicator.
• For greater accuracy and consistency of
the doses, it is recommended that you
set each Selection Indicator.
• The dose can be set by pulses or by
mass (weight).
Operating Procedure
to start the calibration procedure.
to proceed with setting and press the T3
• This parameter enables the technician
to set some scale parameters like:
- Enabling/disabling
parameter;
- Setting the weight reading time;
- Calibrating the scales;
- Updating the scale software.
to confirm.
to confirm. At the end of the process,
button to update the scale firmware if necessary.
the offset
and T2 buttons to
