modbar av Series Manual page 18

6) Waste water drain connection
The espresso machine drain is to be
connected by means of the included
reinforced plastic tubing. Connect one
end of the reinforced plastic tubing to the
drain hose connection on the left side of
the espresso machine, secure with included
hose clamp. Connect the other end to a
suitable waste water collection system.
T.D.S. ppm
Total Hardness ppm
Total Iron (Fe /Fe ) ppm
+2 +3
Free Chlorine (Cl ) ppm
2
Total Chlorine (Cl ) ppm
2
pH value
Alkalinity ppm
Chloride (Cl ) ppm
–
N.B.: Test water quality (the warranty is void if water parameters are not within the range
specified in the section "installation")
18
In case such a system is not available,
drained liquids may be collected in a
suitable bucket and any necessary drain pipe
extensions shall be made using steel-lined
PVC tubing and suitable hose clamps.
Water specifications table
Min.
90
70
0
0
0
6,5
40
not more
Max.
150
100
0,02
0,05
0,1
8,5
80
50
