Order from Master:
Designation
Content
Byte No.
Reply from Slave:
Designation
Content
Byte No.
18
18
AK = 8 (order identification = write parameter value long Array)
PNU = 480 (= 0x1E0)
IND = 3
PWEh = 0xFFFF
PWEl = 0x8AD0
PKE
Parameter
identification
High Low
Byte Byte
0x81 0xE0
0 1
AK = 5 (reply identification = transmit parameter value long Array)
PNU = 480 (= 0x1E0)
IND = 3
PWEh = 0xFFFF
PWEl = 0x8AD0
PKE
Parameter
identification
High Low
Byte Byte
0x51 0xE0
0 1
PKW area
IND PWE high
Index Parameter value
High Word
High Low High
Byte Byte Byte
3 0 0xFF
2 3 4
PKW area
IND PWE high
Index Parameter value
High Word
High Low High
Byte Byte Byte
3 0 0xFF
2 3 4
PWE low
Parameter value
Low Word
Low Byte High Byte Low Byte
0xFF 0x8A 0xD0
5 6
PWE low
Parameter value
Low Word
Low Byte High Byte Low Byte
0xFF 0x8A 0xD0
5 6
