Example:
Parameter
000F STP: 2000 3: 0000 4: 0000 5: 0000 6: 0000
PKE: 6
PKE: 480
IND: 03 00
PWE: -005500
CTR: 000F
STP: 2000
3: 0000
4: 0000
5: 0000
6: 0000
Parameter
VAL: 2000 3: 1147 4: 0CCC 5: 0800 6: 0000
PKE: 5
PKE: 480
IND: 03 00
PWE: -005500
STA: 06A7
VAL: 2000
3: 1147
4: 0CCC
5: 0800
6: 0000
36
36
DP-Master OUT
281 = PKE: 6 480 IND: 03 00 PWE: -005500 CTR:
Order identification = 6 (Read parameter value Array)
Parameter number = 480 (Fixed frequency 1)
Data set = 3
Parameter value = -5500 = -55.00 Hz (0xFFFEA84 hexadecimal)
Release command (transition 4)
Set point = 0x2000 = 50% of the reference value
not used
not used
not used
not used
DP-Master IN
284 = PKE: 5 480 IND: 03 00 PWE: -005500 STA: 06A7
Reply identification = 5 (Transmit parameter value long Array)
Parameter number = 480 (Fixed frequency 1)
Data set = 3
Parameter value = -5500 = -55.00 Hz (0xFFFEA84 hexadecimal)
State = 0x27 "Operation enabled" (Bit 0 ... 6),
Warning 2 available (Bit 15 = 1 threat of fault switch-off),
reference value reached (Bit 10 = 1),
remote operation (Bit 9 = 1),
Warning available (Bit 7 = 1)
Actual value = 0x2000 = 50% of the reference value
Abs. current = 0x1147 = 27% of the rated motor current
Active current = 0x0CCC = 20% of the rated motor current
Warning, Warning motor temperature available
Fault, no fault available
Actual value
Meaning
Actual value
Meaning
