Actual Value Display Of Profibus Data - BONFIGLIOLI ACTIVE Manual

10.3
For analysis purposes,
the data transmitted via the Profibus under the actual value parameters.
The parameters are in the "Actual values \ Actual values frequency inverter"
menu point of the VPlus program and can only be looked at with the latter.
In these parameters, the data transmitted via the Profibus are displayed in a proc-
essed and comprehensible form. The contents of the process data channel with con-
trol word, reference value etc. are permanently updated. As the communication chan-
nel has the contents zero in idling and transmission is very quick, the contents of the
communication channel are stored on the device side and displayed in the actual value
parameters with every transmission.
The displayed content of the communication channel accordingly do not correspond to
the current state, but the last transmission.
Note:
The following diagram shows the display for an object of type PPO2. The contents
also apply for the other objects, PPO1, PPO3 and PPO4. In these objects, a part quan-
tity is displayed each time.
Parameter
cccc STP: ssss 3: xxxx 4: xxxx 5: xxxx 6: xxxx
PKE: a
PKE: nnn
IND: ii
PWE: ww..w ww..w = parameter value
CTR: cccc
STP: ssss
3: xxxx
4: xxxx
5: xxxx
6: xxxx
Parameter
VAL: ssss 3: xxxx 4: xxxx 5: xxxx 6: xxxx
PKE: a
PKE: nnn
IND: ii
PWE: ww..w ww..w = parameter value
STA: cccc
VAL: ssss
3: xxxx
4: xxxx
5: xxxx
6: xxxx
06/05
06/05

Actual value display of Profibus data

DP-Master OUT
The use of the VPlus program with simultaneous use of the Profibus-DP
communication module CM-PDP is only possible with the KP232 serial
adapter on the slot of the KP500 control unit.
DP-Master OUT
281 = PKE: a nnn IND: ii 00 PWE: wwwwww CTR:
= order identification hexadecimal
a
nnn = parameter number decimal
ii = index
cccc = control word
ssss = reference value
xxxx = 0000
xxxx = 0000
xxxx = 0000
xxxx = 0000
DP-Master IN
284 = PKE: a nnn IND: ii 00 PWE: wwwwww STA: cccc
= reply identification hexadecimal
a
nnn = parameter number decimal
ii = index
cccc = state word
ssss = actual value
xxxx = abs. current
xxxx = active current
xxxx = Warning
xxxx = Fault
DP-Master IN
281 and
Actual value
Meaning
hexadecimal
decimal (with sign in front)
hexadecimal
hexadecimal, relative to
0x4000 = 100% of the reference value
not used
not used
not used
not used
Actual value
Meaning
hexadecimal
decimal (with sign in front)
hexadecimal
hexadecimal, relative to
0x4000 = 100% of the reference value
hexadecimal, relative to 0x4000 = 100%
of the rated motor current
hexadecimal, relative to 0x4000 = 100%
of the rated motor current
hexadecimal (bit-coded)
hexadecimal
284 are displayed in
