5
The baud rate is not explicitly set. The Profibus component supports the Auto_Baud
function and independently determines the baud rate set on the bus.
6
A maximum of 126 slave frequency inverters can be operated on the Profibus-DP.
Each frequency inverter is given a node ID for its unambiguous identification; this ID
may only exist once in the system. The setting of the node ID is done via the parame-
ter
Note:
7
As a function of the application in question, various objects with differing lengths and
contents are used for the exchange of data. The objects PPO1, PPO2, PPO3 and
PPO4 are available. These objects are set up according to the PROFIDRIVE profile.
The required object is to be set on the DP master in the hardware configuration.
There is no setting for the required object on the frequency inverter, it sets itself
automatically to the projected object.
Note:
06/05
06/05

Baud rate setting/line length

Baud rate
9,6 kBaud
19,2 kBaud
45,45 kBaud
93,75 kBaud
187,5 kBaud
500 kBaud
1500 kBaud
3000 kBaud
6000 kBaud
12000 kBaud

Setting station address

Profibus Node-ID
391.
Parameter
No. Description
391 Profibus Node-ID
After the setting of the station address via
is automatically triggered on the frequency inverter, by which the setting
for the station address is accepted.

Setting PPO type

PPO type
1
2
3
4
More information on the contents of the objects PPO1 to PPO4, is to be
inferred from the chapter "Handling of the objects".
Profibus-DP interface
max. line length / m
1200
1200
1200
1200
1000
400
200
100
100
100
Profibus - Objects
Objects length / Bytes
12
20
4
12
Setting
Min. Max.
0 126
Profibus Node-ID
Fact. sett.
126
391, a reset
9
