Product Overview

4 Product Overview
4.1 VLT ®
The Danfoss VLT
4 4
®
Each VLT drive is configurable, compatible, and efficiency-optimized for all standard motor types, which avoids the
restrictions of motor-drive package deals.
Benefits of VLT
•
Available in various enclosure sizes and protection ratings.
•
98% efficiency reduces operating costs.
•
Unique back-channel cooling design reduces the need for more cooling equipment, resulting in lower installation
and recurring costs.
•
Lower power consumption for control room cooling equipment.
•
Reduced ownership costs.
•
Consistent user interface across the entire range of Danfoss drives.
•
Application-oriented start-up wizards.
•
Multi-language user interface.

4.2 Enclosure Size by Power Rating

1) 1)
kW Hp
110 150
132 200
160 250
200 300
250 350
315 450
355 500
400 600
450 600
500 650
560 750
Table 4.1 Enclosure Power Ratings, 380–480 V
1) All power ratings are taken at normal overload.
Output is measured at 400 V (kW) and 460 V (hp).
12
High-power Drives
®
drives described in this manual are available as free-standing, wall-mounted, or cabinet-mounted units.
®
Drives
Available enclosures
D1h/D3h/D5h/D6h
D1h/D3h/D5h/D6h
D1h/D3h/D5h/D6h
D2h/D4h/D7h/D8h
D2h/D4h/D7h/D8h
D2h/D4h/D7h/D8h
E1h/E3h
E1h/E3h
E1h/E3h
E2h/E4h
E2h/E4h
Danfoss A/S © 01/2018 All rights reserved.
®
VLT AQUA Drive FC 202
1)
kW
75
90
110
132
160
200
250
315
400
450
500
560
630
710
800
Table 4.2 Enclosure Power Ratings, 525–690 V
1) All power ratings are taken at normal overload.
Output is measured at 690 V (kW) and 575 V (hp).
1) Available enclosures
Hp
75 D1h/D3h/D5h/D6h
100 D1h/D3h/D5h/D6h
125 D1h/D3h/D5h/D6h
150 D1h/D3h/D5h/D6h
200 D1h/D3h/D5h/D6h
250 D2h/D4h/D7h/D8h
300 D2h/D4h/D7h/D8h
350 D2h/D4h/D7h/D8h
400 D2h/D4h/D7h/D8h
450 E1h/E3h
500 E1h/E3h
600 E1h/E3h
650 E1h/E3h
750 E2h/E4h
950 E2h/E4h
MG22B222
