8.9 E1h Exterior and Terminal Dimensions
8.9.1 E1h Exterior Dimensions
2043
(80.4)
2002
(78.8)
1553
(61.1)
1393
(54.9)
912
(35.9)
Figure 8.70 Front View of E1h
MG22B222
Design Guide
22 (0.8)
3X
393 (15.5)
602 (23.7)
Danfoss A/S © 01/2018 All rights reserved.
13 (0.5)
8
8
123
