Product Overview
Enclosure size
Power rating
Output at 400 V (kW)
Output at 460 V (hp)
Protection rating
IP
4 4
UL type
Hardware options
Stainless steel back channel
Mains shielding
Space heater
RFI filter (Class A1)
Safe torque off
No LCP
Graphical LCP
Fuses
Heat sink access
Brake chopper
Regen terminals
Load share terminals
Fuses + load share
Disconnect
Circuit breakers
Contactors
24 V DC supply (SMPS, 5 A)
Dimensions
Height, mm (in)
Width, mm (in)
Depth, mm (in)
Weight, kg (lb)
Table 4.4 E1h–E4h Drives, 380–480 V
1) All power ratings are taken at normal overload. Output is measured at 400 V (kW) and 460 V (hp).
2) If the enclosure is configured with load share or regen terminals, then the protection rating is IP00, otherwise the protection rating is IP20.
3) S = standard, O = optional, and a dash indicates that the option is unavailable.
14
1)
3)
Danfoss A/S © 01/2018 All rights reserved.
®
VLT AQUA Drive FC 202
E1h E2h
355–450 500–560
500–600 650–750
IP21/54 IP21/54
Type 1/12 Type 1/12
O O
O O
O O
O O
S S
O O
O O
S S
O O
O O
O O
– –
– –
O O
– –
– –
– –
2043 (80.4) 2043 (80.4)
602 (23.7) 698 (27.5)
513 (20.2) 513 (20.2)
295 (650) 318 (700)
E3h E4h
355–450 500–560
500–600 650–750
2) 2)
IP20 IP20
Chassis Chassis
O O
– –
– –
O O
S S
O O
O O
O O
O O
O O
O O
O O
O O
– –
– –
– –
– –
1578 (62.1) 1578 (62.1)
506 (19.9) 604 (23.9)
482 (19.0) 482 (19.0)
272 (600) 295 (650)
