8.4 D4h Exterior and Terminal Dimensions

8.4.1 D4h Enclosure Dimensions
59 (2.3)
868 (34.2)
Figure 8.20 Front View of D4h
MG22B222
Design Guide
176 (6.9)
611 (24.1)
