How to Order a Drive
In bottom/out top, E3h
In bottom/out top, E3h
In bottom/out top, E4h
In back/out back, E1h
In back/out back, E2h
In back/out back, E3h
In back/out back, E4h
In bottom/out back, E3h
In bottom/out back, E3h
In bottom/out back, E4h
In back/out top, E3h
In back/out top, E4h
LCP
LCP 101
LCP 102
LCP cable
13 13
LCP kit, IP21
LCP kit, IP21
LCP kit, IP21
External options
EtherNet/IP
Table 13.12 Kits Available for Enclosures E1h–E4h
214
®
VLT AQUA Drive FC 202
Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit is used only for enclosure E3h
with the 600 mm (21.6 in) base plate.
Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit used only for enclosure E3h with
800 mm (31.5 in) base plate.
Allows the cooling air to be directed in through the bottom and out
through the top of the drive. This kit is used only for enclosure E4h
with the 800 mm (31.5 in) base plate.
Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E1h.
Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E2h.
Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E3h.
Allows the cooling air to be directed in and out through the back of
the drive. This kit is used only for enclosure E4h.
Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosure E3h
with the 600 mm (21.6 in) base plate.
Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit used only for enclosure E3h
with the 800 mm (31.5 in) base plate.
Allows the cooling air to be directed in through the bottom and out
through the back of the drive. This kit is used only for enclosure E4h
with 800 mm (31.5 in) base plate.
Allows the cooling air to be directed in through the back and out
through the top of the drive. This kit is used only for enclosure E3h.
Allows the cooling air to be directed in through the back and out
through the top of the drive. This kit is used only for enclosure E4h.
Numerical local control panel (NLCP).
Graphical Local control panel (GLCP).
Separate LCP cable, 3 m (9 ft).
Panel mounting kit including graphical LCP, fasteners, 3 m (9 ft) cable
and gasket.
Panel mounting kit including numerical LCP, fasteners and gasket.
Panel mounting kit for all LCPs including fasteners, 3 m (9 ft) cable
and gasket.
Ethernet master.
