Example of MOVIGEAR
[1]
[2]
[3]
[4]
performance
3
2
X
3 Nm
[3]
"Straight" design
"Angled" design
The tightening torque for the union nut is 3 Mn.
You can order suitable tools from TE Connectivity - Intercontec products using
the following order number:
• Socket wrench 3 Nm, 1/4" external square driver: C1.020.00
• Hook wrench 1/4" square socket, suitable to the 923/723 series with
SpeedTec equipment: C6.216.00
Between plug connector and bushing is a gap of 2 mm.
[4]
2 mm
2
[1]
Operating Instructions – MOVIGEAR
Electrical installation
Plug connectors
3
X
[2]
9007224476469899
®
performance
