Connection cable
M12, -5‑pin,
A‑coded, fe-
male
M12, 5‑pin,
A‑coded, fe-
male
M12, 5‑pin,
A‑coded, fe-
male
M12, 5‑pin,
A‑coded, fe-
male
Connection of cables with open end
The following tables show the conductor assignment of cables with the following part
numbers:
Part number
28117808
28110986
Conformity/
part num-
ber
CE/UL:
28110994
M12, 5‑pin,
A‑coded, male
CE/UL:
28117816
Open
CE/UL:
28111028
M12, 5‑pin,
A‑coded, male
CE/UL:
28111044
Open
Signal name Core color
1)
24V_OUT –
F_STO_P2 White
1)
0V24_OUT –
F_STO_P1 Brown
F_STO_M Green
Electrical installation
Optional plug connector assignment
Cable type Length/in-
stallation
type
igus chainflex Variable
CF78.UL
igus chainflex Variable
CF78.UL
igus chainflex Variable
CF78.UL
igus chainflex Variable
CF78.UL
Identification
–
–
–
–
–
Operating Instructions – MOVIGEAR
5
Cable
cross sec-
tion/operat-
ing voltage
2
4 x 0.5 mm
/
DC 60 V
2
4 x 0.5 mm
/
DC 60 V
2
4 x 0.5 mm
/
DC 60 V
2
4 x 0.5 mm
/
DC 60 V
Prefabrication
Cut off
