Electrical installation
5
Terminal assignment
76
Operating Instructions – MOVIGEAR
Assignment
Terminal No Name
.
X1 1 L1
line terminals
2 L2
3 L3
11 L1
12 L2
13 L3
– PE
X3 1 BR
braking re-
2 BR
sistor termin-
als
X9 1 F_STO_P1 Yellow
control ter-
2 F_STO_P1 Yellow
minals
3 0V24_OUT –
4 24V_OUT
11 F_STO_M
12 F_STO_M
13 24V_IN
14 24V_IN
21 F_STO_P2 Yellow
22 F_STO_P2 Yellow
23 0V24_IN
24 0V24_IN
X42 1 TX+
fieldbus in-
2 TX-
terface
1) 3 RX+
port 1
6 RX-
X43 1 TX+
fieldbus in-
2 TX-
terface
1) 3 RX+
port 2
6 RX-
®
performance
Marking Function
Brown Line connection, phase L1 – IN
Black Line connection, phase L2 – IN
Gray Line connection, phase L3 – IN
Brown Line connection, phase L1 – OUT
Black Line connection, phase L2 – OUT
Gray Line connection, phase L3 – OUT
– PE connection
– Braking resistor connection
– Braking resistor connection
Input STO+
Input STO+
(to loop through)
0V24 reference potential
for DC 24 V auxiliary output
– DC 24 V auxiliary output
Yellow Input STO_ground
Yellow Input STO_ground
(to loop through)
– DC 24 V supply
– DC 24 V supply
(to loop through)
Input STO+
Input STO+
(to loop through)
– 0V24 reference potential
for DC 24 V supply
– 0V24 reference potential
for DC 24 V supply
(to loop through)
– Transmit line +
– Transmit line -
– Receive line +
– Receive line -
– Transmit line +
– Transmit line -
– Receive line +
– Receive line -
