Service
8
Fault table standard
8.7.8 Fault 10 Data Flexibility
Subfault: 10.1
Description: Initialization
Response: Application stop + output stage inhibit
Init task error.
Subfault: 10.2
Description: Illegal operation code
Response: Application stop + output stage inhibit
Illegal opcode in Data Flexibility program.
Subfault: 10.3
Description: Memory access
Response: Application stop + output stage inhibit
Memory area violated while accessing array.
Subfault: 10.4
Description: Stack
Response: Application stop + output stage inhibit
Overflow of Data Flexibility stack detected.
Subfault: 10.5
Description: Division by 0
Response: Application stop + output stage inhibit
Division by 0.
Subfault: 10.6
Description: Runtime
Response: Application stop + output stage inhibit
Runtime error/watchdog.
PDI or PDO tasks.
168
Operating Instructions – MOVIGEAR
Cause
Cause
Cause
Cause
Cause
Cause
®
performance
Measure
The init task has issued a return code != 0. Check
the program.
Measure
Contact SEW-EURODRIVE Service.
Measure
For example an array access results in writing
beyond the permitted memory range. Check the
program.
Measure
Check the program.
Measure
Check the program.
Measure
Check the program. The program execution time
exceeds the permitted time.
Check the program. The execution time of the
PDI or PDO task exceeds the permitted time.
