Startup
6
DIP switches
6.3.2 Description of the DIP switches
DIP switch S1/1: Direction of rotation reversal (PROFINET, EtherNet/IP™, Modbus TCP)
DIP switch S1/2: Disable holding function without enable (PROFINET, EtherNet/IP™, Modbus TCP)
130
Operating Instructions – MOVIGEAR
INFORMATION
The direction of rotation is reversed depending on the setting of the DIP switch and of
the parameter drive train 1 > Controller >
tings are active, the speed setpoint is not inverted (logical XOR).
You can reverse the direction of rotation of the drive using this DIP switch.
• OFF (S1/1 = OFF): The drive turns CW for a positive setpoint and CCW for a neg-
ative setpoint.
• ON (S1/1 = ON): The drive turns CCW for a positive setpoint and CW for a negat-
ive setpoint.
WARNING
Risk from falling loads.
Severe or fatal injuries.
• Do not activate the function "Disable holding function without enable" for hoist
applications and applications with potentially falling loads.
INFORMATION
For more information about disabling DynaStop
chapter "Operation".
INFORMATION
If the function of this DIP switch is disabled via parameter access, the last active set-
ting is maintained.
Use this DIP switch to disable the holding function (DynaStop
enabled.
• OFF (S1/2 = OFF): You cannot deactivate the holding function without drive en-
able.
• ON (S1/2 = ON): You can deactivate the holding function without drive enable. The
holding function is then controlled via digital input or process data bit.
®
performance
Direction of rotation reversal. If both set-
®
without drive enable, refer to the
®
) even if the drive is not
