Service
8
Description of status and operating displays
LED
Red
Steady light
"L/A" LEDs (left)
LED
Green
Illuminated
Yellow
Illuminated
"L/A" LEDs (right)
LED
Green
Illuminated
Yellow
Illuminated
158
Operating Instructions – MOVIGEAR
Operating status/
Fault Subfault code
code
1 1, 2
4 2
7 2
9 3, 4, 8
10 2, 99
11 7, 8
13 1, 3, 6, 7, 8, 9, 11,
13, 15, 22, 23
16 2, 11, 12. 30
17 7
18 1, 3,4, 7, 8, 9, 10,
12, 13
20 1.7
21 1
23 5, 6, 7, 8
25 10, 12 – 19, 50, 51,
81
28 13
33 1, 2, 6, 7, 8, 10
46 1
Meaning
There is no Ethernet connection to Ethernet port 1.
An Ethernet connection exists from Ethernet port 1 to an additional Ethernet con-
sumer.
Meaning
There is no Ethernet connection to Ethernet port 2.
An Ethernet connection exists from Ethernet port 2 to an additional Ethernet con-
sumer.
®
performance
Meaning
Output stage monitoring fault
Brake chopper fault
DC link fault
Control mode fault
Data Flexibility fault
Temperature monitoring fault
Encoder 1 fault
Startup fault
Internal processor fault
Software error
Device monitoring fault
S-Drive 1 fault
Power section fault
Parameter memory monitoring
FCB drive function fault
System initialization fault
Safety card fault
Measure
Contact SEW-
EURODRIVE
Service.
