Promet I.S. User's Manual
3.2.2

Powering-up the Analyzer

For the AC power supply version of the Promet I.S., turning on the power switch on the
back panel of the control unit will power-up the control unit and the two transmitters
for each channel connected. There is no power switch for the DC power supply version.
It is turned on automatically once 24 V DC power source is applied.
After turning on the analyzer the display will be illuminated. The default Main Reading
Page displays sample dew point (°C) and sample pressure (barg).
NOTE. Depending on your order, the pressure value can be real-time readings
from the pressure transmitter if the model with active pressure compensation
(order code: P1/P2) is ordered, or manual set value if the model without active
pressure compensation (order code: G) is ordered (see Section 3.2.2.2).

3.2.2.1 Change Units

From the Main Reading Page, press the
readings in sequence as shown below:
Michell Instruments
6 5. 0 B
Default
DEG C
- 2 2. 1 C
Display
6 5. 0 B
DEG F
- 7. 9 F
Display
6 5. 0 B
PPMV I
1 2. 4 7
Display
6 5. 0 B
L B M M C F
Display
6 5. 0 B
MG/M3
Display
6 5. 0 B
PPMV N
Display
Units of Measurement Readings in Sequence
Figure 22
key to change the units of measurement
Display
Pressure
Dew point
Pressure
Dew point
Pressure
ppm ideal gas
V
Pressure
1. 1 5
Lbmmscf natural gas
Pressure
1 9. 6 1
mg/m 3 natural gas
Pressure
2 5. 7 4
ppm natural gas
V
OPERATION
o
C
o
F
